IDT KD01

Kammprofile gasket for tongue and groove flanges.


Description

KD01

KD01

Concentrically grooved profile on both sides and covered with soft material layers.

Layers
graphite (0.5 mm or 0.8 mm) or PTFE (0.5 mm)
Kammprofile pitch
1.0 mm (other pitches on request)
Core material
1.4571 (other materials on request)
IDT identification
Kammprofile gasket with soft sealing layer
IDT Style
KD01
Pressure
Up to max. 400 bar
Temperature with graphite layers
-200 °C up to 450 °C (550 °C)
Please consult the manufacturer as temperature above 450°C
Temperature with PTFE layers
-200 °C up to 250 °C
Application
Steel flanges, steel vessels
Dimensions
DIN 2690 / ANSI / EN 1514-TG
Special–purpose dimensions are available on request
