Description

KD20

KD20

The metallic core is made with a concentrically grooved profile on both sides and a machined centering ring, additionally provided with a pre-determined breaking point.

Layers
graphite (0.5 mm or 0.8 mm) or PTFE (0.5 mm)
Kammprofile pitch
1.0 mm (other pitches on request)
Core material
1.4571 (other materials on request)
IDT identification
Kammprofile gasket with soft sealing layer
IDT Style
KD20
Pressure
Up to max. 400 bar
Temperature with graphite layers
-200 °C up to 450 °C (550 °C)
Please consult the manufacturer as temperature above 450 °C
Temperature with PTFE layers
-200 °C up to 250 °C
Application
Steel flanges, steel vessels
Dimensions
DIN 2690 / ANSI / EN 1514
Special–purpose dimensions are available on request
